ACM066 Automatic Brazing Flux

        The series of FBA product is a perfect choice of flux for automatic brazing process,in which the system requires several key physical properties of the flux paste, namely, high stability (no percipitation), fine granularity,absolute purity, and the right amount of fluidity ( thixotropy ). These requirements are based on the applicator of the system and other processes.

         Also, the chemical property of the flux in the system is even higher required because of the brazing process control limits. To meet the requirements,we carefully adjusted the components of the FBA product and tried on more than ten different kinds of automatic brazing machines and made sure it works on all of them. Properties: High long-term flux activity,viscosity about 190Pa.s, color of brown,granularity of 300 screen mesh(about 50um).

       Operation: This series of product is often used in automatic brazing process although it is also to function in manual brazing operation.It can be injected into automatic brazing machine and transported in tubes with pressed air.The paving needless (applicator) are normally used to put the paste onto the brazing parts,such as diamond,hard alloy bit,cemented carbide and so on.

       Storage:Storage without direct sunbeam,well ventilation,and avoid contact with children.Do not eat.

        Technical info: This series of brazing paste are on the paste of organic fluid solvent with the right features of fluidity,flammability,evaporability,and polarity which combined can make the very fine flux powder suspend,uniformly,perform with excellent chemical-flux activity,and also long-term stability.The organic solvent can be vaporized and decomposed at the temperature of brazing process with no carbon residue,which means the chemical activity of the flux can be well contained.Furthermore,at the normal storage condition ,the fluid hardly vaporizes to initiate any kinds of agglomeration,which used to be a big problem for water based paste.Given the fact that the agglomeration is not generated in the system,the series of FBA product can be perfectly used on the tubes in an automatic coating system.

Yantai TiBright Welding Materials Co. Ltd., founded in 2000, is a professional developer and international supplier of inclusive brazing materials, equipment, and consultant. TiBright has hundreds of products for different applications. Customized products are also available for specific purposes.

         When choose from our product library, please check out our recommended product list, If you have any questions, please let us know, We will try our best to satisfy your inquiry. Sometimes we need our customers to try different samples to make the perfect decision. Generally, we need to know the following information to choose a right product for you.

1. Materials of your parenting parts (to-be-brazed parts).

2. Heating methods. (eg. flame, induction, vacuum furnace etc. )

3. Atmosphere of application. (eg. room air, protective inert gas, reductive gas, vacuum, etc.)

4. Dimensions of your parts. Photos or graphs are preferred. (Different dimensions require different procedures.)

5. Current solution. (eg. brazing materials, equipment, procedures, etc.)

6. The reasons of searching new solution. (eg. price, strength, applicability, etc.)

7. Industry of your application. (Help us refer to similar examples.)

Normal packaging:

Other packing can be customized according to customer's requirement

         With hundreds of products in our product library, TiBright is a professional developer and international supplier of inclusive brazing materials, equipment, and consultant.

One highlight of our services is that we provide customized products specially designed for specific customers. We have a lot of successful cases in which the customers had the products suitable for their own procedures, environment and operation routines perfectly.
          We also provide entire brazing solution for customers to solve all the problems related to brazing process. We provide consultant for customers with complicated applications and innovative demand.

          About sixty percent of our equipment and devices are designed and crafted in our own machine workshop, which engaged us the ability of prompt reaction towards new updates from customers. We also produce specially designed brazing tools and machines. We often develop products together with our customers for their individual needs.
